Drivers have a universal input included on most models. This accepts most of the Gems Sensors linear output types. Not all output types provided by Gems sensors are supported by West controllers, so you should verify the required output is supported.

In this example, the Gems 3100 Series Pressure Transducer is able to send DC voltage outputs of 0-5, 1-5, and 0-10 VDC, or it can send 4-20 mA (milliamp) current. These values are scaled to match the pressure range the transducer was configured for. For instance, using the 4-20 mA output for 0-750 PSIG (pounds per square inch, gauge) would cause the transducer to provide 4 mA when there is 0 PSI and 20 mA when there is 750 PSI in the container and showing on the pressure gauge. The West 6100 Plus Series Controller has the universal input where 4-20 mA is programmed, and the 0-750 scale is configured for the full range.
